OTHER ALLOYS

By clicking any of the maroon colored links, you will be directed to our main site of South Coast Industrial Metals

MATERIALS & APPLICABLE SPECIFICATIONS

(FLANGE, RING AND BAR PRODUCTS)

GRADE UNS NO. FORGING SPECS BAR SPECS
* F304 S30400 A/SA182, A/SA 403, QQ-S-763 A276, A/SA 479
* F304H S30409 A/SA182, A/SA 403, QQ-S-763 A276, A/SA 479
* F304L S30403 ALL ABOVE + AMS 5647 A276, A/SA 479
F304N S30451 A/SA182, A/SA403 A/SA479
F304LN S30453 A/SA182 NONE
* F309 S30900 A/SA 403, QQ-D-763 A276
* F310 S31000 A/SA182, A/SA 403, QQ-S-763 A276
* F310S S31008 QQ-S-763 A276,A/SA479
* F316 S31600 A/SA182, A/SA 403, QQ-S-763 A276,A/SA479
* F316H S31609 A/SA182, A/SA 403, QQ-S-763 A276,A/SA479
* F316L S31603 ALL ABOVE + AMS 5653 A276,A/SA479
316N S31651 A/SA182, A/SA403 A276
F316LN S31653 A/SA182 A276
* F317 S31700 A/SA182, A/SA 403, QQ-S-763 A276
* F317L S31703 A/SA182 NONE
* F321 S32100 A/SA 182, A/SA 403, AMS 5645 A276,A/SA479
* F321H S32109 A/SA182, A/SA 403 A/SA 479
* F347 S34700 A/SA 182, A/SA 403, AMS 5646/5654 A276,A/SA479
* F347H S34709 A/SA182, A/SA 403 A/SA 479
F44 (254 SMO)- 1 S31254 A/SA182 A276
* F45 (253 MA)- 2 S30815 A/SA182 A276,A/SA479
F47 (317LM) S31725 A/SA182 A276,A/SA479
F48 (317LMN) S31726 A/SA182 A276,A/SA479
F430 S43000 A/SA182 A276,A/SA479
* F6a (410) S41000 A/SA 182, AMS 5613 A276,A/SA479
F6NM S41500 A/SA182 NONE
* F410S S41008 A/SA 182 (F6A), AMS 5613 A276,A/SA479
NITRONIC 50 S20910 A/SA 182, A/SA 403 (XM-19) A/SA 479 (XM-19)
NITRONIC 60 S21800 NONE A276,A/SA479
15-5 PH S15500 A564, AMS 5659 NONE
17-4 PH S17400 A/SA 564 (630), AMS 5643 NONE
* F51 (DUPLEX) S31803 A/SA182 A276,A/SA479
* F60 (2205) S32205 A/SA182 NONE
* F53 (2507) – 6 S32750 A/SA182 A/SA 479
* F55 (Zeron 100) S32760 A/SA182 A/SA479
* F61 (Ferr. 255) S32550 A/SA 182 A/SA 479
* A105 CS K03504 A/SA 105 NONE
* A350 LF-1 K03009 A/SA 350 NONE
* A350 LF-2 K03011 A/SA 350 NONE
A350 LF-3 K32025 A/SA 350 NONE
* F5 (501SS) K41545 A/SA182 NONE
* F5a K42544 A/SA182 NONE
* F9 K90941 A/SA182 NONE
* F11 CL-1 K11597 A/SA182 NONE
* F11 CL-2 K11572 A/SA182 NONE
* F11 CL-3 K11572 A/SA182 NONE
* F12 CL-1 K11562 A/SA182 NONE
* F12 CL-2 K11564 A/SA182 NONE
* F22 CL-1 K21590 A/SA182 NONE
* F22 CL-3 K21590 A/SA182 NONE
* ALUM 1100 A91100 B/SB 247, B/SB 361 B/SB 211, B/SB 221
* ALUM 3003 A93003 B/SB 247, B/SB 361 B/SB 211, B/SB 221
* ALUM 5083 A95083 B/SB 247, B/SB 361 B/SB 221
* ALUM 5086 A95086 NONE B/SB 221
* ALUM 6061 A96061 B/SB 247,B/SB 361, QQ-A-367,
AMS4127/4146
B/SB 211,
B/SB 221
* 70/30 CUNI C71500 MIL-C-15726, MIL-C-24679 B/SB 151
* 90/10 CU-NI C70600 MIL-C-15726, MIL-C-24679 B/SB 151
* EVER 655 C65500 B/SB 283 (HOT PRESSED) B/SB 98
NAVAL BRASS C46400 B/SB 283 (HOT PRESSED) NONE
* TITANIUM GR 2 R50400 B/SB 363, B/SB 381 B/SB 348
* TITANIUM GR 7 R52400 B/SB 363, B/SB 381 B/SB 348
* TITANIUM GR 12 R53400 B/SB 363, B/SB 381 B/SB 348
TITANIUM 15-3-3-3 R58153
HAYNES HR 160 – 4 N12160 B564 B/SB 572
* HAYNES 230 – 4 N06230 B/SB 564, AMS 5891 B/SB 572
* HAYNES 242 – 4 N10242 B564, HAYNES PS-6085-2 B/SB 573
HAYNES 556 – 4 R30556 HAYNES PS-6042-2B B/SB 572
* 7-MO PLUS (F52) – 3 S32950 A/SA182 A/SA 479
HASTELLOY-B2 – 4 N10665 B462, B366 (REF), B/SB 564 B/SB 335
* HASTELLOY-B3 – 4 N10675 B462, B366 (REF), B/SB 564 B/SB 335
HASTELLOY-C4 – 4 N06455 B366 B/SB 574
* HASTELLOY-C22 – 4 N06022 B462, B366 (REF), B/SB 564 B/SB 574
* HASTELLOY-C276 – 4 N10276 B/SB462, B/SB 564, AMS 5750 B/SB 574
* HAST C-2000 – 4 N06200 B/SB462, B/SB 564 B/SB 574
* HASTELLOY-G30 – 4 N06030 B/SB 462, B366 B/SB 581
HASTELLOY-X – 4 N06002 B366 (REF), AMS 5754 B/SB 572
* NICKEL 200 N02200 B366 (REF), B/SB 564 B/SB 160
* NICKEL 201 N02201 B366 (REF) B/SB 160
* ALLOY 400 N04400 B366, B/SB 564, QQ-N-281,
MIL-F-23509
B/SB 164
ALLOY K500 N05500 QQ-N-286 NONE
* ALLOY 600 N06600 B366 (REF), B/SB 564, AMS 5665 B/SB 166
* ALLOY 601 N06601 AMS 5715 B/SB 166
INCONEL 617 – 5 N06617 B564 B166
* ALLOY 625 N06625 B366 (REF), B/SB 564, AMS 5666 B/SB 446
INCONEL 686 – 5 N06686 B/SB 564, AMS 5891 B/SB 574
INCONEL 690 – 5 N06690 B564 B/SB 166
INCONEL 718 – 5 N07718 B/SB 637, AMS 5662/5663/5664 B/SB 637
INCONEL X750 – 5 N07750 B/SB 637, (GR 688), AMS 5542/5668 B/SB 637
* ALLOY 800 N08800 B 366 (REF), B/SB 564, AMS 5766 B/SB 408
* ALLOY 800H N08810 B 366 (REF), B/SB 564 B/SB 408
* ALLOY 800HT N08811 B 366 (REF), B/SB 564 B/SB 408
* ALLOY 825 N08825 B 366 (REF), B/SB 564 B/SB 425
* ALLOY 904L N08904 NONE B/SB 649
* ALLOY C20 (F20) N08020 A 182, B 366, B/SB 462, B/SB 564 B/SB 472, B/SB 473
* AL6XN (F62) – 2 N08367 A/SA 182, B 366, B/SB 462, B/SB 564 B/SB 472, B/SB 691
* ALLOY 330 N08330 B 366 (REF), AMS 5716 B/SB 511, B/SB 512
* ALLOY 333 N06333 AMS 5717 B 719
25-6 MO – 5 N08925 NONE B/SB 649
ALLOY 59 N06059 B 564 B 574
ULTIMET R31233 NONE (REF: HAYNES MATERIAL) B 815
* ELGILOY N030003

  * MATERIALS IN STOCK
1 – Registered Trademark of Outokumpu Corp.
2 – Registered Trademark of Allegheny Ludium Corp.
3 – Registered Trademark of Carpenter Tech.
4 – Registered Trademark of Haynes International
5 – Registered Trademark of Special Metals Corp
6 – Registered Trademark of Sandvik Steel

AluminumPipeFittings.net is a division of South Coast Industrial Metals.  We offer stock from Los Angeles, CA 3003H112, 5086H32 & 6061T6 Fittings from ½” – 8″ Long Radius 90’s, Long Radius 45’s, Long Radius 180’s, Short Radius 90’s, Short Radius 180’s, Tees (Straight and Reducing) Tees and Crosses (Straight and Reducing) Caps, Concentric Reducers, Eccentric Reducers, Laterals and Wyes (Straight and Reducing)  We also offer custom manufactured nickel alloy pipe fittings.  We also offer 10″ – 48″ custom manufactured fittings, flanges and pipe.  For more information, please contact us:  RFQ@scimetals.com :: (949) 218-0026
